Nano Ceramics Carbon -- Automotive

Nano Ceramics Carbon -- Automotive

Download Specifications
FEATURES

--- Good for both Automotive and Building windows

--- High in IR blocking and heat reduced.

--- Not blocking GPS or mobile network

--- Protect car indoor furnishing

--- Easy apply to curve windows with heat gun

--- Nano ceramics film without metal



HIGHLIGHTS

IR Nano ceramics series for all automotive/commercial/residential; non-reflective ceramics apply on the films. IR ceramics film is a non-metalized coating film. It is known for best Infrared rejection. High in transmission for visible light, and low outer light reflection; the series could be use both for cars and buildings.



As a manufacturer, we are able to make all kinds of films based upon your request:

---VLT

---Color

---Thickness

---IR Reject

---Customized Packing & Logo

Please feel free to use our ENQUIRY FORM to tell us what you like!



Product code CR VLT IR Reject UV cut Type Total Solar Energy Rejection Solar Heat Gain Coefficient
CR70
70%±3% 90% 99% Nano Ceramic 61% 0.38
CR50
50%±3% 90% 99% Nano Ceramic 75% 0.34
CR30
32%±3% 90% 99% Nano Ceramic 79% 0.34
CR15
13%±1.5% 90% 99% Nano Ceramic 89% 0.24
CR05
6%±1% 90% 99% Nano Ceramic 97% 0.21
CS80
80%±3% 70% 99% Nano Ceramic 51% 0.54
CS50
50%±3% 70% 99% Nano Ceramic 52% 0.45
CS30
32%±3% 70% 99% Nano Ceramic 68% 0.43
CS15
13%±1.5% 70% 99% Nano Ceramic 78% 0.42
CS05
6%±1% 70% 99% Nano Ceramic 89% 0.40
CF30
30%±2% 48% 99% Carbon Ceramic 62% 0.54
CF15
15%±1.5% 55% 99% Carbon Ceramic 71% 0.48
CF05
6%±1% 70% 99% Carbon Ceramic 86% 0.41
