PRODUCTS



FEATURES

--- Best in IR blocking and heat reduced

--- Hybrid in Carbon & Ceramics, to enhance the results

--- Will Not block GPS nor mobile network

--- Most stable in color

--- Lower overall energy cost



HIGHTLIGHTS

Carbon film series is for automotive/commercial/residential. This line stands for the latest trend of the window tinting industry; utilizing carbon as the heat rejecter, it could ultimately lower the IR and UV in the most effective way possible. By different applications, it also equipped with ceramics and metals for some specific requirements.



As a manufacturer, we are able to make all kinds of films based upon your request:

---VLT

---Color

---Thickness

---IR Reject

---Customized Packing & Logo

Please feel free to use our ENQUIRY FORM to tell us what you like!



Product code CR VLT IR Reject UV cut Color / Design Total Solar Energy Rejection Solar Heat Gain Coefficient
FARH-BC05
6%±1% 82% 99% Ceramics Carbon 91% 0.31
FARH-BC10
13%±1.5% 81% 99% Ceramics Carbon 85% 0.34
FARH-BC20
20%±1.5% 78% 99% Ceramics Carbon 80% 0.41
FNRH-8686
68%±3% 58% 99% Ceramics Carbon 51% 0.55
FNRH-8787
70%±3% 50% 99% Ceramics Carbon 50% 0.58
FNRH-8760
65%±3% 47% 99% Ceramics Carbon 53% 0.54
FNRH-8702
37%±3% 63% 99% Ceramics Carbon 59% 0.50
FNRH-8803
14%±1.5% 76% 99% Ceramics Carbon 80% 0.41
FNRH-8505
8%±1% 85% 99% Ceramics Carbon 80% 0.40
FNRH-9903
15%±1.5% 80% 99% Ceramics Carbon 85% 0.35
FNRH-9907
13%±1.5% 79% 99% Ceramics Carbon 84% 0.35
FNRH-9911
6%±1.5% 86% 99% Ceramics Carbon 91% 0.25
FNRH-5305
5%±1% 82% 99% Ceramics Carbon 89% 0.26
FNRH-5315
13%±1.5% 86% 99% Ceramics Carbon 81% 0.40
FNRH-5335
30%±2% 65% 99% Ceramics Carbon 70% 0.45
