FEATURES

--- Best in IR blocking and heat reduced

--- Hybrid in Carbon & Ceramics, to enhance the results

--- Will Not block GPS nor mobile network

--- Most stable in color

--- Lower overall energy cost



HIGHTLIGHTS

Carbon film series is for automotive/commercial/residential. This line stands for the latest trend of the window tinting industry; utilizing carbon as the heat rejecter, it could ultimately lower the IR and UV in the most effective way possible. By different applications, it also equipped with ceramics and metals for some specific requirements.



As a manufacturer, we are able to make all kinds of films based upon your request:

---VLT

---Color

---Thickness

---IR Reject

---Customized Packing & Logo

Please feel free to use our ENQUIRY FORM to tell us what you like!



Product code CR VLT IR Reject UV cut Color / Design Interior Reflection Exterior Reflection Total Solar Energy Rejection Solar Heat Gain Coefficient
FARH-BC05
6%±1% 82% 99% Ceramics Carbon 15.6% 19.5% 91% 0.31
FARH-BC10
13%±1.5% 81% 99% Ceramics Carbon 15.6% 19.4% 85% 0.34
FARH-BC20
20%±1.5% 78% 99% Ceramics Carbon 14.4% 19.4% 80% 0.41
FNRH-8686
68%±3% 58% 99% Ceramics Carbon 19.5% 16.4% 51% 0.55
FNRH-8787
70%±3% 50% 99% Ceramics Carbon 15.4% 13.4% 50% 0.58
FNRH-8760
65%±3% 47% 99% Ceramics Carbon 16.1% 13.9% 53% 0.54
FNRH-8702
37%±3% 63% 99% Ceramics Carbon 12.2% 17.2% 59% 0.50
FNRH-8803
14%±1.5% 76% 99% Ceramics Carbon 13.6% 20.7% 80% 0.41
FNRH-8505
8%±1% 85% 99% Ceramics Carbon 10.9% 24.3% 80% 0.40
FNRH-9903
15%±1.5% 80% 99% Ceramics Carbon 12.1% 20.1% 85% 0.35
FNRH-9907
13%±1.5% 79% 99% Ceramics Carbon 11.0% 19.5% 84% 0.35
FNRH-9911
6%±1.5% 86% 99% Ceramics Carbon 13.8% 21.2% 91% 0.25
FNRH-5305
5%±1% 82% 99% Ceramics Carbon 10.9% 17.4% 89% 0.26
FNRH-5315
13%±1.5% 86% 99% Ceramics Carbon 11.5% 17.1% 81% 0.40
FNRH-5335
30%±2% 65% 99% Ceramics Carbon 9.4% 16.5% 70% 0.45
