Nano Ceramics Carbon -- Buildings
Download Specifications
FEATURES
--- Good for both Automotive and Building windows
--- High in IR blocking and heat reduced.
--- Not blocking GPS or mobile network
--- Protect indoor furnishing
--- Lower overall energy cost
--- Nano ceramics film without metal
HIGHLIGHTS
IR Nano ceramics series for all automotive/commercial/residential; non-reflective ceramics apply on the films. IR ceramics film is a non-metalized coating film. It is known for best Infrared rejection. High in transmission for visible light, and low outer light reflection; the series could be use both for cars and buildings.
As a manufacturer, we are able to make all kinds of films based upon your request:
---VLT
---Color
---Thickness
---IR Reject
---Customized Packing & Logo
Please feel free to use our ENQUIRY FORM to tell us what you like!
Product code | CR | VLT | IR Reject | UV cut | Type | Total Solar Energy Rejection | Solar Heat Gain Coefficient |
---|---|---|---|---|---|---|---|
CR70 |
|
70%±3% | 90% | 99% | Nano Ceramic | 61% | 0.38 |
CR50 |
|
50%±3% | 90% | 99% | Nano Ceramic | 75% | 0.34 |
CR30 |
|
32%±3% | 90% | 99% | Nano Ceramic | 79% | 0.34 |
CR15 |
|
13%±1.5% | 90% | 99% | Nano Ceramic | 89% | 0.24 |
CR05 |
|
6%±1% | 90% | 99% | Nano Ceramic | 97% | 0.21 |
CS80 |
|
80%±3% | 70% | 99% | Nano Ceramic | 51% | 0.54 |
CS50 |
|
50%±3% | 70% | 99% | Nano Ceramic | 52% | 0.45 |
CS30 |
|
32%±3% | 70% | 99% | Nano Ceramic | 68% | 0.43 |
CS15 |
|
13%±1.5% | 70% | 99% | Nano Ceramic | 78% | 0.42 |
CS05 |
|
6%±1% | 70% | 99% | Nano Ceramic | 89% | 0.40 |
CF30 |
|
30%±2% | 48% | 99% | Carbon Ceramic | 62% | 0.54 |
CF15 |
|
15%±1.5% | 55% | 99% | Carbon Ceramic | 71% | 0.48 |
CF05 |
|
6%±1% | 70% | 99% | Carbon Ceramic | 86% | 0.41 |
