Energy Saving Low Reflective
Download Specifications
FEATURES
--- High visible light transmission that dramatically reduce solar energy
--- Superb performance at a lower cost than Nano Ceramics Film
--- Outstanding color stability and durability
--- Reducing color fading and banding
--- Transparent & comfortable
HIGHLIGHTS
This line stands for the latest trend of the window tinting industry; utilizing metal and ceramics as the heat rejecter, It could ultimately lower the IR and UV in the most effective way possible. By different applications, it also equipped with ceramics and metals for some specific requirements.
Product code | CR | VLT | IR Reject | UV cut | Color / Design | Total Solar Energy Rejection | Solar Heat Gain Coefficient |
---|---|---|---|---|---|---|---|
INRH-BC05 |
![]() |
6%±1% | 90% | 99% | Ceramic Reflective | 93% | 0.15 |
INRH-BC10 |
![]() |
11%±1.5% | 90% | 99% | Ceramic Reflective | 91% | 0.24 |
INRH-BC20 |
![]() |
20%±1.5% | 90% | 99% | Ceramic Reflective | 85% | 0.33 |
INRH-9921 |
![]() |
7%±1% | 90% | 99% | Ceramic Reflective | 92% | 0.19 |
INRH-9920 |
![]() |
15%±1.5% | 90% | 99% | Ceramic Reflective | 90% | 0.25 |
INRH-9922 |
![]() |
35%±3% | 90% | 99% | Ceramic Reflective | 80% | 0.32 |
FA-BC05 |
![]() |
6%±1% | 82% | 99% | Carbon Reflective | 91% | 0.31 |
FA-BC10 |
![]() |
13%±1.5% | 81% | 99% | Carbon Reflective | 85% | 0.34 |
FA-BC20 |
![]() |
20%±1.5% | 78% | 99% | Carbon Reflective | 80% | 0.41 |
FA-8686 |
![]() |
68%±3% | 58% | 99% | Carbon Reflective | 51% | 0.55 |
FA-8787 |
![]() |
70%±3% | 50% | 99% | Carbon Reflective | 50% | 0.58 |
FA-8760 |
![]() |
65%±3% | 47% | 99% | Carbon Reflective | 53% | 0.54 |
FA-8702 |
![]() |
37%±3% | 63% | 99% | Carbon Reflective | 59% | 0.50 |
FA-8803 |
![]() |
14%±1.5% | 76% | 99% | Carbon Reflective | 80% | 0.41 |
FA-8505 |
![]() |
8%±1% | 85% | 99% | Carbon Reflective | 80% | 0.40 |
FA-9903 |
![]() |
15%±1.5% | 80% | 99% | Carbon Reflective | 85% | 0.35 |
FA-9907 |
![]() |
13%±1.5% | 79% | 99% | Carbon Reflective | 84% | 0.35 |
FA-9911 |
![]() |
6%±1% | 86% | 99% | Carbon Reflective | 91% | 0.25 |
FA-5305 |
![]() |
5%±1% | 82% | 99% | Carbon Reflective | 89% | 0.26 |
FA-5315 |
![]() |
13%±1.5% | 86% | 99% | Carbon Reflective | 81% | 0.40 |
FA-5335 |
![]() |
30%±2% | 65% | 99% | Carbon Reflective | 70% | 0.45 |
